GEM GK450/GK480/GK450-ST/GK480-ST Electric Strike

The GK450/480 series ANSI electric strike is designed for use with cylindrical locksets and mortises locksets without a deadbolt and can be installed in metal and wood door frames.It includes an optional latch monitor and is field reversible for fail-safe or fail-secure operation. The GK485 features 1/8″ (3mm) horizontal strike adjustment to accommodate different installations.

Standard Features:
◆ Non-handed fully reversible
◆ Field reversible fail-safe or fail-secure
◆ Static strength 1,500 lbs (680Kg)
◆ Dynamic strength 70 ft-lbs
◆ Endurance 100,000 cycles UL tested, 1,000,000 cycles factory tested
◆ Brushed stainless steel (US32D) finish

Optional Feature
◆ Latch monitor

Patents, Approvals, and Listings
◆ UL 1034 burglary resistant listed : BP10269
◆ UL 294 Access Control System listed: BP10269
◆ Tested to 30 minutes (no failure) in accodrance with EN1634-1:2014
(For GK450M-ST-1224)

Specification:
◆ Voltage: 12/24 VDC
◆ Current Draw: 1300mA/12VDC, 150mA/24VDC
◆ Latch Throw: GK450, GK450-ST (9/16″ (15mm)), GK480, GK480-ST (3/4″ (19mm))
◆ Optional latch monitor
◆ Reversible Fail-safe or Fail-secure
◆ Frame: Hollow metal
◆ Body construction: Zinc alloy, Stainless steel.
